Machine Specification



Gildemeister

Model TWIN 32

​

Year 2001

Specification



• Siemens Sinumerik 840D Control



• Twin turrets with 12 stations

​

• Sub Spindle​

​

• High Pressure Coolant

​

• Swarf conveyor​

​

• Iemca Vip 80 Bar Feeder

​

• Distance between centres: 580mm

​

• Displacement working X1 × Z1: 220×320mm

• ​

• Displacement working X2 × Z2: 120×340mm

​

• Spindle bore: 50 mm

​

• Maximum cutting length: 320 mm

​

• Spindle range: 40-8000 rpm

​

• M/C Footprint 3910 × 2340 × 1985mm

​

• Weight 6000Kg
